Universal Joint

제품종류

전자카달로그/회사소개서 다운로드

경/중하중용 크로스핀타입

UD - type

페이지 정보

UJTECH 0

16,597 2015.05.08 22:03

첨부파일


0 2015-07-01 21:59:41

0 2015-06-21 13:10:01

본문

Product name		UD10	UD12	UD14	UD16	UD20	UD25	UD30	UD35	UD40	UD45	UD50
Allowable conditional variable		80,000	121,000	151,000	200,000	273,000	406,000	531,000	711,000	918,000	1,150,000	1,400,000
Max. Speed	min¯¹	2,000	1,800	1,600	1,400	1,000	800	700	600	500	400	300
Tcs	Nm	61	100	140	230	390	750	1,100	1,800	2,700	3,500	4,300
Tdw	Nm	20	33	46	76	129	248	363	594	891	1,155	1,419
β (angle)	°	30	30	30	30	30	30	30	30	30	30	30
d	mm	10	12	14	16	20	25	30	35	40	45	50
D	mm	19	23	26	30	36	44	50	59	67	75	83
LD	mm	67.5	83	94.5	117.5	139	168	195	224	251	282	304
A	mm	25.5	31	35.5	43.5	52	63	73	84	94	106	113
L	mm	21	26	29.5	37	43.5	52.5	61	70	78.5	88	95.5
C	mm	12	15	17	22	25	30	35	40	45	50	55
E	mm	6	7.5	8.5	11	12.5	15	17.5	20	22.5	25	27.5
P	mm	4.5	5	5.8	6.5	8	10	11.5	13	14.5	16	17.5
K	mm	3	4	5	5	6	7 (8)	7 (8)	10	10 (12)	12 (14)	12 (14)
t	mm	11.4	13.8	16.3	18.3	22.8	28 (28.3)	33 (33.3)	38.3	43.3 (43.5)	48.5 (48.8)	53.5 (53.8)
M	mm	5	5	6	6	6	8	8	10	10	10	10
Ts	kg	1,300	2,300	2,600	3,900	5,200	8,100	10,000	14,000	18,000	22,000	28,000
Weight	g	95	180	250	410	690	1,240	1,775	3,180	4,150	6,225	7,750

Refer to“ Allowable Conditional Variables” on Page 19 before selecting one.
β : Maximum deflection angle per joint
Tcs : Functional limit Torque
Ts : Static tensile load
Tdw : Fatigue Torque

| How to Order :

UD	25	K7 or P	×	D44	×	168	ex ) UD25K7xD44x168
TYPE	d	K(Key width) or P	×	D	×	LD	ex ) UD25K7xD44x168
