Universal Joint

고하중용

UT - type

페이지 정보

5,776   2015.05.08 22:29

첨부파일

본문

Product name UT100 UT120 UT150 UT160 UT180 UT225 UT250 UT285 UT315 UT350 UT390
Bearing mm Ø32x92(57) Ø39.68x117 Ø52x133 Ø52x133 Ø57x144 Ø72x185 Ø95x217 Ø110x247 Ø120x275 Ø135x307 Ø160x334
Tcs kNm 2.4 5 10 10 12 43 80 120 160 225 320
Tdw kNm 0.7 1.6 4 4 4.5 13 40 58 80 110 160
β (angle) ° 24 24 35 35 35 24 15 15 15 15 15
A (flange) mm 100 120 150 160 180 225 250 285 315 350 390
K (swing dia.) mm 98 136 158 158 170 215 250 285 315 350 390
B (pcd) mm 84 101.5 130 140 155.5 196 218 245 280 310 345
C mm 57 75 90 100 110 140 140 175 175 220 250
F mm 3 3 3 4 4 6 6 6 7 7 8
G mm 10 10 12 12 14 15 25 27 32 35 40
I (qty of holes) - 6 8 8 8 8 8 8 8 10 10 10
H mm 9 10 12 12 14 16 19 21 23 23 25
M mm 62 72 90 90 100 108 160 180 200 220 240
X mm - - - - - - 40 40 40 50 70
Y mm - - - - - - 12.5 15 15 16 18
S (tube) mm 76.3x3.65 90x80 89.1x7.6 89.1x7.6 101.6x8.1 139.8x9.5 168x14 194x16 216x18.2 273x19 273x36
W (spline) - 33.33-m1.667 50-m1.5 65-m2.5 65-m2.5 75-m2.5 85-m2.5 115-m2.5 150-m3 150-m3 185-m5 185-m5
Lz (min.) mm 310 425 590 590 630 700 960 1,055 1,165 1,270 1,420
La (stroke) mm 40 120 120 120 120 120 140 140 140 150 170
G kg 6 16 33 34 46.5 80 172 263 382 532 738
Gr kg 6.54 10.48 15.3 15.3 18.7 30.5 53 70 88.9 119 210.4
d1 (max.) mm 40 50 60 70 80 105 115 130 155 170 190
D1 (max.) mm 64 80 105 110 125 172 191 215 248 278 309
L1 mm 63 80 90 110 125 160 175 200 235 255 285
d2 (max.) mm 60 70 90 95 110 140 155 175 195 215 240
L2 mm 90 110 140 160 180 210 235 270 300 330 370
  • Tcs : Functional limit Torque
  • Tdw : Fatigue Torque
  • Lz(Order Production) : Shortest possible compressed length
  • La : Length compensation
  • G : Weight of shaft
  • Gr : Weight per 1,000mm tube
  • β : Maximum deflection angle per joint
  • Lz + La : Maximum operating length
  • | How to Order :
UT 150 × 1500 (+120)
TYPE A LZ La
